The Hydraforce 5122101U (5122101U) is a sophisticated screw-in, cartridge-style valve known as the TS10-36X, designed for precise pressure control in hydraulic systems. This pilot-operated, spool-type, proportional pressure reducing/relieving valve allows for infinite adjustment across a specified range through variable electric input. The regulated pressure is directly proportional to the electrical current applied to the valve coil. When current is applied, the TS10-36XX enables flow from port 2 to port 1 until the pressure at port 1 offsets the solenoid force and opens the pilot section. Upon reaching the set pressure at port 1, the valve restricts inlet flow at port 2 to maintain regulated pressure at port 1 and simultaneously relieves excess pressure from port 1 to port 3. In scenarios where no current is applied, it defaults to relieve pressure at approximately 100 psi (6.9 bar). This model comes with standard coil options of 12 and 24 volts and offers optional waterproof E-Coils that are rated up to IP69K for high durability in harsh environments. It features an industry-common cavity design and an optional manual override for enhanced versatility in various applications.
