SV80-61-6T-N-12DS SOLENOID VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5008812 (5008812) is a solenoid-operated, 2-position, 6-way, direct-acting, spool-type, screw-in hydraulic cartridge valve designed for versatile fluid control in hydraulic systems. This model facilitates precise operation by blocking or allowing flow between specific ports depending on its energized or de-energized state. When de-energized, the SV8061 configuration of the valve blocks flow to ports 5 and 6 while enabling flow between ports 4 and 3, and between ports 1 and 2. Conversely, when energized, it shifts to block flow to ports 2 and 3 and permits flow between ports 4 and 5, as well as between ports 1 and 6. This valve is particularly useful in applications where selective direction of flow is needed to operate two cylinders of unequal area ratios. For optimal performance in such setups, it is recommended that the cylinder head sides be connected to ports 3 and 5, with rod sides connected to ports 2 and 6. Key features enhancing its functionality include a hardened precision spool and cage which ensure longevity even under demanding conditions. It also offers optional coil voltages and terminations to suit various operational requirements. Moreover, the Hydraforce 5008812 is equipped with heavy-duty waterproof E-Coils that are rated up to IP69K for robust performance in harsh environments. The continuous-duty rated coil underscores its capability for sustained operations without degradation of performance. Additionally, cartridges are designed to be voltage interchangeable which adds a layer of flexibility for system design or upgrades without complete valve replacement.
