3DR10P5-6X/50Y/00V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3DR10P5-6X/50Y/00V (R900973873) is a sophisticated pressure reducing valve designed to effectively manage and reduce system pressure in hydraulic circuits. The valve, which is pilot-operated, ensures the limitation of the secondary circuit's pressure through its main valve with a control spool and a pilot control valve that includes a pressure adjustment element. In its initial position, the 3DR10P5-6X/50Y/00V allows unrestricted flow from channel P to A, while simultaneously applying pressure to the piston area opposite the compression spring through a bore. This action also affects the spring-loaded side of the control spool and the ball in the pilot control valve. The setting of the compression spring determines when pressure will build up and hold the control spool in an open position, allowing fluid to flow until a balance is achieved between channel A's pressure and that set on the compression spring. This balance ensures that if any external force increases channel A's pressure, the control spool will move towards a closed position to maintain desired reduced pressure levels. Additionally, should this pressure increase further, hydraulic fluid is discharged into the tank via channel T to prevent any further increase. For monitoring purposes, there's a gauge connection available for checking reduced pressure in channel A. The valve is designed for subplate mounting with porting patterns conforming to DIN form A, ISO and CETOP RP 121 H standards. It comes with different adjustment elements including rotary knobs and sleeves with protective caps for precise adjustments. With its maximum operating pressure of bar and maximum flow rate of l/min, this Bosch Rexroth valve stands out for its reliability in maintaining system pressures within desired parameters across various applications.
