3DR10P5-6X/200Y/00MSO63

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3DR10P5-6X/200Y/00MSO63 (R901211014) is a high-performance pressure reducing valve designed for efficient control of system pressure. This pilot-operated way pressure reducing valve is equipped with a main valve that includes a control spool and a pilot control valve with an adjustable pressure element. It operates by allowing hydraulic fluid to flow from channel P to channel A without restriction while the system is in its initial state. As the fluid moves, it applies pressure to both the piston area and the spring-loaded side of the control spool, ensuring that the valve remains open until a predefined pressure level is reached. The sophisticated design of this model allows for precise regulation, ensuring that when the pressure in channel A surpasses the set value, the ball opens, causing the control spool to shift into a closed position and establish the desired reduced pressure. If external forces increase channel A's pressure further, this valve can discharge excess hydraulic fluid into the tank through channel T, preventing any potential overpressure. This Bosch Rexroth valve also features an external pilot oil return via port Y and includes a pressure gauge connection for monitoring reduced pressures in channel A. Its compatibility with various subplate mounting options conforms to DIN form A, ISO standards, and CETOP RP 121 H specifications. Users can select from different adjustment elements such as rotary knobs and lockable rotary knobs with scales for ease of use. With its ability to handle maximum operating pressures up to bar and maximum flow rates up to l/min, this component reflects Bosch Rexroth's commitment to delivering reliable and precise hydraulic solutions suitable for various applications requiring accurate pressure reduction and limitation within hydraulic systems.
