3DR10P4-6X/200Y/00V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3DR10P4-6X/200Y/00V (R900917797) is a sophisticated pressure reducing valve designed to manage and limit system pressure within hydraulic circuits. This pilot-operated way pressure reducing valve is notable for its ability to maintain a reduced system pressure by controlling the flow from channel P to channel A. It features a main valve with a control spool and a pilot control valve that includes a pressure adjustment element, ensuring precise regulation of hydraulic fluid. In its initial state, the valve allows unrestricted flow from channel P to A while the pressure in channel A acts upon the piston area opposite the compression spring, influencing the control spool's spring-loaded side through a nozzle. The setting of the compression spring determines when pressure builds up upstream, holding the control spool in an open position until the set pressure is exceeded and balance is achieved. The design accommodates external forces acting on the actuator by allowing increased pressure in channel A to push against the compression spring, connecting channel A to T via a control edge on the spool. This connection discharges excess hydraulic fluid into the tank, preventing further pressure increases. The external pilot oil return via port Y requires a depressurized connection to ensure proper operation. Additionally, this model includes a pressure gauge connection for monitoring reduced pressure in channel A. Designed for subplate mounting with porting patterns according to DIN form A, ISO, and CETOP standards, this valve offers different adjustment elements such as rotary knobs (with or without scales), sleeves with hexagon and protective cap, and lockable rotary knobs with scale for diverse application needs. The Bosch Rexroth 3DR10P4-6X/200Y/00V serves as an integral component in hydraulic systems requiring precise pressure reduction and limitation capabilities.
