BALL RUNNER BLOCK CARBON STEEL KWC-055-FLS-C2-U-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FLS-C2-U-2 (R165352910) is a ball runner block designed for high precision linear motion applications. This runner block is part of the Ball Rail Systems product line, specifically tailored for heavy machine construction with an emphasis on maximum rigidity and high load-bearing capacity. The model boasts a steel CS body and offers ultra precision (UP) accuracy with medium preload class C, ensuring reliable performance in demanding environments. Key features include a flanged, long, standard height (FLS) format, absence of a ball chain for simplified maintenance, and angular lube nipples that are loosely attached to facilitate lubrication. The runner block is preserved but comes without initial lubrication or attachment elements on either front reference edge. It's designed to accommodate heavy-duty applications with improved rigidity under various loading conditions and has additional mounting screw holes at the center for enhanced stability. The Bosch Rexroth runner block is noted for its smooth, quiet operation due to an optimized ball return system and guideway design. Its entry-zone geometry and the high number of balls reduce elastic deflection variation, offering consistent motion control. The unit's innovative channel design ensures minimal lubrication requirements while maintaining performance. This model is versatile in its application; it can be used with all SNS Ball Guide Rails and allows for limitless interchangeability among all ball guide rail versions. Attachments can be mounted from both above and below the runner block, providing flexibility in system design. The product also includes end-face fastening threads for various attachments. With its robust construction and precise engineering, the Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FLS-C2-U-2 (R165352910) is equipped to meet the stringent requirements of heavy-duty industrial applications where precision linear movement is critical.
