BALL RUNNER BLOCK CARBON STEEL KWC-055-FLS-C3-S-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FLS-C3-S-2 (R165353110) is a high-precision ball runner block designed for demanding applications requiring maximum rigidity and heavy load-bearing capacity. This runner block features a size FLS format, which indicates a flange width, long length, and standard height. The body of the runner block is made from unalloyed steel CS, ensuring durability and strength. With a preload class C indicating high preload and an accuracy class SP for super precision, this component is engineered to deliver exceptional performance. It does not include a ball chain and comes preserved but without initial lubrication. The angular lube nipples are loosely attached for easy maintenance. The overall length of the runner block measures . mm, providing substantial support for various uses. Designed for heavy machine construction, this runner block can withstand high torque loads and offers improved rigidity under liftoff and side loading conditions due to additional mounting screw holes at its center. The innovative channel design allows for minimal lubrication quantities while ensuring smooth and quiet operation through an optimally designed ball return system and guideway. The entry zone geometry is optimized with a high number of balls to minimize variation in elastic deflection. This Bosch Rexroth model offers different preload classes and end-face fastening threads for attachments that can be mounted from both above and below the runner block. It is compatible with all SNS Ball Guide Rails, allowing limitless interchangeability between all versions of ball guide rails and ball runner blocks. The product's static load rating C0, dynamic torsional moment load capacity Mt, dynamic load capacity C, static longitudinal moment load capacity ML are determined based on DIN ISO standards with variations provided for different sizes of profiled rail systems. Its design also accounts for ambient temperature tolerances between minimum ... maximum °C. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FLS-C3-S-2 (R165353110) is a versatile solution designed to meet the requirements of heavy-duty applications where precision movement and high load capacities are critical.
