BALL RUNNER BLOCK CARBON STEEL KWC-055-FLS-C1-N-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FLS-C1-N-2 (R165351410) is a high-precision ball runner block designed for linear motion applications that demand the utmost in rigidity and load-bearing capacity. This runner block is part of the CS series, featuring a steel construction with a standard accuracy class N and low preload class C, ensuring smooth operation with minimal elastic deflection. It has an overall length of . mm and is preserved but does not come with initial lubrication or attachment elements on the left or right front reference edges. This product excels in heavy-duty machine construction, offering maximum rigidity in all load directions. Its robust design includes two additional mounting screw holes at the center for improved stability under liftoff and side loading conditions. The runner block also boasts high torque load capacity and can accommodate attachments from both above and below, providing versatility in assembly. The innovative channel design ensures minimum lubrication requirements, contributing to the smooth and quiet running of the system. The optimized ball return and guideway, along with an entry zone geometry that houses a high number of balls, further minimize noise and vibration during operation. One of the key features of this runner block is its limitless interchangeability; it can be combined with all SNS ball guide rail versions without restriction. This flexibility allows users to tailor their linear motion systems to specific requirements without compatibility concerns. Additionally, various seals such as standard SS, low-friction LS, double-lip DS, front seal options, FKM seal for extreme environments, and cover plate wipers are available to protect against contaminants like dirt, chips, coolants, or cutting fluids—extending the service life of the Ball Runner Block. With its comprehensive design features focusing on durability, precision interchangeability, and protection against harsh operating conditions, this Bosch Rexroth Ball Runner Block is an ideal component for sophisticated linear motion solutions.
