CLAMPING ELEMENT MKS 3505 KB ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT MKS 3505 KB (R161934062) is a high-performance pneumatic clamping unit designed for use with ball rail systems. This robust clamping element is compatible with SNS ball guide rails and is engineered to provide dynamic and static stabilization in the axial direction. Its mechanical gripping principle ensures optimal performance with an excellent price-to-performance ratio, making it a cost-effective solution for various applications. With its chemically nickel-plated steel housing, the MKS 3505 KB offers high axial and horizontal rigidity, ensuring precise positioning and a secure hold. The unit boasts higher holding forces facilitated by the airplus port, which enhances its clamping capability. It features a dual-action gate valve gear mechanism supported by two spring assemblies that enable the clamp to engage without pressurization; in the event of a pressure drop, it automatically secures itself, ensuring safety and reliability. The integrated quick-exhaust valve in the MKS 3505 KB guarantees short response times for efficient operation. It has been tested to withstand up to 1 million clamping cycles, indicating its durability and long service life. The product operates effectively within a permissible ambient temperature range of -30°C to +80°C and can withstand maximum pneumatic operating pressures while maintaining exact positioning, high dynamics, powerful drive capabilities. This clamping element has been designed with ease of mounting in mind and can be used across various profiled rail systems including sizes A, E, H, B, N, and S. The release pressure minimum stands at 2 bar while offering an impressive spring energy holding force that varies depending on the air port used—standard or airplus. Overall, the Bosch Rexroth CLAMPING ELEMENT MKS 3505 KB is an essential accessory for profiled rail systems requiring reliable pneumatic clamping or braking units. Its design ensures both functionality and longevity in demanding industrial environments where precision and rigidity are paramount.
