CLAMPING ELEMENT KWH 3505 AS2A ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT KWH 3505 AS2A (R161934251) is a high-precision hydraulic clamping unit designed for dynamic and static stabilization in the axial direction of ball rail systems. It is characterized by its compact design, making it compatible with DIN standards and offering versatility across various applications. This clamping element can be utilized on all SNS ball guide rails, ensuring broad compatibility within the Bosch Rexroth linear motion technology range. The unit boasts a solid, rigid steel housing that is chemically nickel-plated to ensure durability and resistance to harsh conditions. It features integrated all-around sealing and utilizes special pressure diaphragm technology to provide maximum functional reliability without pressure losses or leakage. The KWH 3505 AS2A model ensures high positioning accuracy and offers continuously adjustable pressure from 50 to 450 bar, enabling precise control over the clamping force. This model is equipped with integrated positive-locking, large-surface contact profiles that deliver maximum axial rigidity, contributing to the overall stability of the system it is applied to. Furthermore, it has been tested for up to 1 million clamping cycles, showcasing its long-term reliability. The clamping element operates under a permissible ambient temperature range from -20°C up to +80°C, accommodating various working environments. Designed for ease of use, the KWH 3505 AS2A features threaded connections on both sides for hydraulic integration. Its functional principle involves using hydraulic pressure (50-450 bar) to clamp with pressure via a piston principle while decompression occurs with spring force through a pretensioned return spring allowing short decompression cycles. This ensures quick response times in operations requiring frequent clamping and releasing actions. In summary, the Bosch Rexroth CLAMPING ELEMENT KWH 3505 AS2A (R161934251) represents an efficient and reliable solution for securing components in place within ball rail systems across a multitude of applications where precision and durability are paramount.
