BRAKING ELEMENT KBH 3505 AS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BRAKING ELEMENT KBH 3505 AS1A (R161934021) is a state-of-the-art hydraulic braking unit designed for use with ball rail systems. This robust component is engineered to provide secure clamping and braking actions under hydraulic pressure, ensuring high positioning accuracy and operational reliability. It features an integrated all-around sealing mechanism that maintains its functionality without pressure losses or leakage, thanks to a special pressure diaphragm technology. The KBH 3505 AS1A can be utilized on all SNS ball guide rails, making it a versatile addition to various linear motion applications. With the capability of up to 2 million clamping cycles and up to 250,000 emergency braking operations, this hydraulic braking unit is built for heavy-duty performance and longevity. Its solid steel housing is chemically nickel-plated for enhanced durability and corrosion resistance. The brake shoes incorporate positivelocking contact profiles which contribute to maximum axial rigidity when engaged. The unit operates efficiently with a release pressure of 50 bar and can be easily connected via threads on both sides for the hydraulic connection. A pretensioned return spring facilitates swift decompression cycles, allowing for seamless operation within the permissible ambient temperature range of -30°C to +80°C. The KBH 3505 AS1A's compact design ensures compatibility with DIN standards while maintaining a low displacement value throughout its service life. Overall, the Bosch Rexroth BRAKING ELEMENT KBH 3505 AS1A offers reliable clamping and braking solutions for demanding applications where precision and durability are paramount. Its advanced design ensures maximum functional reliability in industrial settings requiring precise linear motion control.
