CLAMPING ELEMENT HK 3505 KB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT HK 3505 KB (R161934283) is a manual clamping unit designed for ball rail systems, offering a simple yet secure clamping mechanism without the need for auxiliary power. This manually operated unit features a freely adjustable hand lever, ensuring precise positioning and ease of use. The symmetrical force application through floating contact profiles provides reliable holding forces up to N, making it suitable for various applications including all SNS ball guide rails and BNS roller guide rails. The HK 3505 KB can be utilized across multiple profiled rail system sizes such as H, E, A, N, L, and B. It is compatible with the Size H profiled rail system and ensures a high level of functionality with a nominal size that fits within these systems. The unit boasts an efficient design that allows for quick and easy manual clamping cycles with an emphasis on safety and compactness. The operational principle of the HK 3505 KB involves manual pressure applied through the hand lever which presses the clamping profiles onto the web surfaces of the Ball Guide Rail. When disengaged, this allows for smooth movement without resistance. The product is designed to operate within a permissible ambient temperature range from -20°C to +80°C. Constructed to deliver durability and performance, this clamping element has been tested under mounted state conditions with an ISO VG lubricated layer to ensure reliability in holding force. It also offers straightforward maintenance due to its accessible design. Overall, the Bosch Rexroth CLAMPING ELEMENT HK 3505 KB is an essential accessory for profiled rail systems requiring secure positioning in various industrial applications where manual operation is preferred or required.
