CURVE 90+ HOR STS 90° R700

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CURVE 90+ HOR STS 90° R700 (3842557058) is a high-quality horizontal sliding curve that facilitates a directional change in conveying systems where space constraints do not allow for a curve wheel or where product dimensions and speeds make the use of a curve wheel impractical. This component is specifically designed for seamless integration with STS VFplus conveyor systems, ensuring a smooth transition in the material flow. The CURVE 90+ HOR STS boasts a deflection angle of 90 degrees and is constructed from non-rusting steel, ensuring durability and longevity even in demanding industrial environments. The effective sliding rail length and actual chain length are tailored to meet specific system requirements, while additional versions can be requested through Bosch Rexroth's modification department to accommodate unique applications. This model comes fully assembled, including all necessary fastening materials for mounting to STS section profiles, simplifying the installation process. To ensure optimal performance, the appropriate slide rail length calculation must be conducted with size 'b' and dimension 'A' taken into consideration. The CURVE 90+ HOR STS 90° R700 is an essential component for any conveyor system requiring reliable horizontal changes in direction under constrained spatial conditions or specific operational demands. Its robust construction and precise engineering reflect Bosch Rexroth's commitment to quality in providing advanced conveying solutions.
