PRESSURE SWITCH HEDE10-3X/400/2/-GA-K35-V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HEDE10-3X/400/2/-GA-K35-V (R901433088) is an advanced electronic pressure switch designed to provide accurate monitoring and control in a variety of applications. This device features a high-quality display for pressure values and parameters, as well as two switching outputs for efficient operation. The pressure switch operates within a pressure range of up to 400 bar, ensuring it can handle demanding tasks with precision. Equipped with an M12 connector that is A-coded according to EN standards, the HEDE10-3X/400/2/-GA-K35-V ensures secure and reliable electrical connections. Its throttle element is integrated into the pressure tube and channel, enhancing the device's functionality. All components that come into contact with media are constructed from durable stainless steel, providing excellent resistance to overload and bursting. The thin-film measuring cell included in this model offers exceptional sensitivity and accuracy. For added convenience, users can configure the switch via IOLink technology or directly through buttons on the device itself. This flexibility allows for easy adaptation to specific system requirements. The hydraulic connection of this pressure switch is a G-threaded type, while its electrical connection description includes a connector pole that adheres to A-coding standards set by EN regulations. It has a maximum pressure rating that ensures safe operation under various conditions. In terms of compliance, the HEDE10-3X/400/2/-GA-K35-V meets several key regulatory standards including CE for electromagnetic compatibility, RoHS Directive for restriction of hazardous substances, UL recognition for safety, UKCA marking for UK conformity assessment, and EAC certification for Eurasian countries. This model operates on a supply voltage of 24 VDC and weighs approximately 0.5 kg. It comes equipped with FKM seals which are compatible with hydraulic fluids such as HL, HLP, HFC, HETG, HEES, and HFD types. With its robust construction and versatile capabilities, this Bosch Rexroth electronic pressure switch is an essential component in ensuring precise control over hydraulic systems.
