DR10DP3-4X/150YV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP3-4X/150YV (R900522399) is a direct operated pressure reducing valve designed for subplate mounting and capable of limiting system pressure in hydraulic applications. This model ensures steady secondary circuit pressure regulation through its adjustment type, maintaining consistent performance under varying loads. The valve's open initial position allows for unrestricted flow from channel B to channel A, with the secondary pressure set via an adjustable compression spring. With internal signal and pilot oil supply via the control line from channel A, this valve efficiently manages fluid dynamics to maintain desired pressure levels. When external forces increase pressure in channel A, the control spool reacts against the compression spring to connect channel A to channel TY, allowing excess hydraulic fluid to discharge into the tank and preventing undue pressure rise. The DR10DP3-4X/150YV features an external leakage oil discharge through channel TY from the spring chamber, ensuring system integrity and performance. An optional check valve can be installed for free flow back from channel A to B, enhancing the valve's versatility in various hydraulic circuits. This model also includes a pressure gauge connection for monitoring secondary pressure and comes with multiple adjustment types such as a rotary knob or a lockable rotary knob with scale for precise control. Designed according to DIN Form D and ISO standards for porting patterns, it offers ease of integration into existing systems. The DR10DP3-4X/150YV is built for durability and reliability, supporting maximum operating pressures up to a certain bar level and maximum flow rates measured in liters per minute (l/min), making it suitable for a wide range of industrial applications where precise pressure reduction is required.
