DR10DP2-4X/75YMV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP2-4X/75YMV (R900504798) is a direct operated pressure reducing valve designed for subplate mounting with a porting pattern according to DIN Form D and ISO standards. This model ensures precise control of system pressure by limiting the secondary circuit through an adjustable mechanism. The valve maintains its open position initially, allowing unrestricted flow from channel B to channel A, while the secondary pressure is set using the adjustment type provided. Featuring internal signal and pilot oil supply via the control line from channel A, the DR10DP2-4X/75YMV valve is engineered to respond dynamically to pressure changes. When the set pressure value is exceeded due to external forces, the control spool moves into a control position, thereby regulating and maintaining constant pressure levels in channel A. This process involves connecting channel A to channel TY through a control edge on the spool, which allows excess hydraulic fluid to be discharged into the tank, preventing significant pressure increases. The model also includes external leakage oil discharge from the spring chamber through channel TY. An optional check valve can be installed for free flow back from channel A to B, enhancing versatility in application. Moreover, it offers convenient monitoring of secondary pressure via a pressure gauge connection. This particular model comes with various adjustment types such as a rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. It supports maximum operating pressures and flow rates defined by its size and component series specifications while also providing an optional check valve for added functionality. The DR10DP2-4X/75YMV valve's robust design ensures reliable performance in controlling system pressures across various hydraulic applications.
