The Bosch Rexroth DR10DP2-4X/25YMV (R900509344) is a high-performance, direct operated pressure reducing valve designed for subplate mounting with porting pattern according to DIN Form D and ISO standards. This model is part of the component series X and is capable of handling a maximum operating pressure up to a specified bar level and facilitating a maximum flow rate measured in liters per minute. It features an initial open position that allows hydraulic fluid to flow freely from channel B to channel A, while also being able to limit system pressure.
The secondary pressure of the Bosch Rexroth DR10DP2-4X/25YMV valve is adjustable via an adjustment type mechanism, ensuring precise control over the system's performance. The valve maintains a constant pressure level in channel A through the movement of the control spool that reacts to changes in pressure against a compression spring. This ensures stability even when external forces affect the actuator.
Furthermore, signal and pilot oil are internally supplied through the control line from channel A. Excess hydraulic fluid can be discharged into the tank via channel TY, preventing undue pressure increase. Additionally, this valve features external leakage oil discharge through channel TY from the spring chamber.
For applications requiring free flow back from channel A to channel B, an optional check valve can be installed in this model. The inclusion of a pressure gauge connection facilitates easy monitoring of secondary pressure levels. The Bosch Rexroth DR10DP2-4X/25YMV offers various adjustment types such as rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale for versatile application adjustments. This robust valve combines precise control with durable construction for reliable operation in various hydraulic systems.
$902.00 USD
More are expected on May 5, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as May 5, 2025 when ordered in
