PRESSURE REDUCING VALVE DR10DP2-4X/210YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP2-4X/210YM (R900501385) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a pre-set value. This direct-actuated spool valve, with a P A spool symbol, is engineered to limit system pressure by ensuring secondary circuit pressure limitation. It features mechanical actuation and supports a maximum pressure as defined by its product group specifications. With its CETOP D size specification, the DR10DP2-4X/210YM valve is suitable for subplate mounting and adheres to connection diagrams based on ISO standards. It has multiple ports for fluid flow and can be actuated mechanically. The maximum flow rate is determined by the size of the valve, which is built to handle various types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. This model incorporates NBR seals and offers optional features such as a check valve for free flow back from channel A to channel B. The secondary pressure can be monitored via a pressure gauge connection point. The adjustment type allows for precise control of the secondary pressure setting. The DR10DP2-4X/210YM valve remains open in its initial position allowing unrestricted flow from channel B to A until the set pressure value is exceeded; at which point it moves into control position maintaining constant pressure levels in channel A. External forces influencing channel A will further adjust the control spool against the compression spring to maintain desired pressures while directing excess hydraulic fluid into the tank through channel TY. This model offers various adjustment types including rotary knobs and threaded pins with protective caps—some versions come with scales for more accurate settings. Its design ensures that leakage oil discharge from the spring chamber is always external via channel TY. The robust construction and versatile capabilities make it suitable for complex hydraulic systems requiring precise pressure control.
