DR10DP2-4X/210YMV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP2-4X/210YMV (R900516873) is a direct operated pressure reducing valve designed for subplate mounting with a porting pattern according to DIN Form D and ISO standards. This valve is utilized to maintain a system's secondary circuit pressure within desired parameters. The secondary pressure can be precisely adjusted through various adjustment types such as a rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or a rotary knob with scale. In its initial position, the valve permits unrestricted hydraulic fluid flow from channel B to channel A. The pressure in channel A is controlled by the piston area opposite the compression spring, which reacts to changes in pressure. When the set value of the compression spring is exceeded, the control spool moves into a control position to stabilize the pressure at a constant level. This model also features internal signal and pilot oil supply via control line from channel A. The DR10DP2-4X/210YMV can manage external force effects on an actuator by allowing excess hydraulic fluid to discharge into the tank through channel TY, ensuring only slight increases in pressure. Additionally, it has an external leakage oil discharge from the spring chamber via channel TY. An optional check valve can be installed for free flow back from channel A to channel B. For monitoring purposes, this model includes a pressure gauge connection for secondary pressure verification. It comes with several options for customization including different adjustment types and an optional check valve. The size of this component series X allows it to handle maximum operating pressures of up to 210 bar and maximum flow rates as specified by Bosch Rexroth's product standards.
