DZ6DP2-5X/150XYV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DZ6DP2-5X/150XYV (R900414525) is a highly specialized direct operated pressure sequence valve designed to facilitate pressure-dependent connection of secondary systems. This valve operates by utilizing a compression spring that holds the control spool in its initial position, blocking flow until the pressure in channel P reaches the set value. When this occurs, the spool moves to allow connection from P to A, enabling the connected system to operate without experiencing a pressure drop in channel P. The DZ6DP2-5X/150XYV features internal or external control signal options via control lines from channel P or port B X. It also offers flexibility in terms of leakage oil discharge, which can be directed externally through port T Y or internally via A, depending on application requirements. However, it's important to note that with internal leakage oil discharge, the set cracking pressure will be influenced by the pressure present in channel A. For those applications requiring a free return flow of hydraulic fluid from channel A back to channel P, an optional check valve can be installed. Additionally, monitoring and adjustment of sequencing pressure are made convenient with a pressure gauge connection. This model is designed for subplate mounting and adheres to DIN form A and ISO standards for porting patterns. It is available without a locating hole as standard or with one per ISO specifications upon request. Subplates need to be ordered separately if required. The DZ6DP2-5X/150XYV offers various options for adjustment types including rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale – all designed for precise control according to user preference. Pressure ratings and maximum flow rates are determined by size and component series designation. In summary, Bosch Rexroth's DZ6DP2-5X/150XYV presents a robust solution for controlling sequencing pressures in complex hydraulic systems while providing flexibility and precision through its various features and optional components.
