L-DB50F2-3X/16

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth L-DB50F2-3X/16 (R900348351) is a sophisticated pressure relief valve that is specifically designed for applications requiring low preload pressure and the capacity to handle high flow rates. This valve is part of the pilot-operated pressure valves of type LDB, which are recognized for their reliable performance in controlling hydraulic pressure. The construction of this valve includes a pipeline installation housing, a main spool guide to accommodate the pilot control valve, and a main spool that ensures precise operation. The functionality of the L-DB50F2-3X/16 involves the pressure in channel P acting on the main spool while also being directed to the pilot control valve through specific nozzles. When the preset pressure at the pilot control valve is exceeded, it triggers an opening, allowing pilot oil to be discharged directly into channel Y. This action causes the main spool to move against spring forces, connecting channel P with channel T whenever the pressure surpasses the set value at the pilot control valve. The model also features a version U, where an external spring solely holds the main spool closed. In circumstances where there's no load on the control channel, this version can achieve a reduced circulation pressure. Additionally, this product offers flexibility with its LDBF variant that operates similarly but comes as a cartridge valve without pipeline housing, suitable for flange connection according to DIN EN standards. It provides ease in pressure adjustments through a sleeve with hexagon and protective cap. Overall, Bosch Rexroth's L-DB50F2-3X/16 offers reliability and adaptability for various hydraulic applications where precise pressure relief is critical. The design and engineering encapsulate Bosch Rexroth's commitment to advanced fluid power solutions.
