BALL RUNNER BLOCK CARBON STEEL KWC-055-FLS-C2-S-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FLS-C2-S-2 (R165352110) is a high-precision ball runner block designed for heavy-duty machine construction and applications demanding utmost rigidity. This runner block is notable for its steel CS construction, medium preload class C, and super precision accuracy class SP. It lacks a ball chain and comes without initial lubrication or attachment elements on either front reference edge. The product features an overall length of . mm and can be used interchangeably with guide rails of every accuracy level, making it highly versatile in application. It is engineered to withstand heavy loads with maximum rigidity in all directions, including improved performance under liftoff and side loading conditions due to the additional mounting screw holes at the center. This runner block operates smoothly and quietly due to its optimally designed ball return system and guideway. The innovative channel design ensures minimum lubrication requirements while the optimized entry zone geometry paired with a high number of balls reduces elastic deflection variation. Attachments on the runner block can be mounted from both above and below, offering flexibility in design integration. The end-face fastening thread accommodates all attachments, enhancing ease of use. It is compatible with all SNS Ball Guide Rails, allowing limitless combinations with other rail versions for tailored system configurations. This product has been preserved but does not come pre-lubricated; it also features angular lube nipples loosely attached for maintenance ease. The B.RUNNER BLOCK CS KWC-055-FLS-C2-S-2 offers a static load rating C0, dynamic torsional moment load capacity Mt, and dynamic load capacity C that are determined based on DIN ISO standards for travel life expectancy. In summary, this Bosch Rexroth ball runner block stands out for its robust construction, precision performance, versatile application potential, and innovative design features aimed at reducing maintenance needs while providing reliable operation in demanding environments.
