BALL RUNNER BLOCK CARBON STEEL KWD-035-FLS-C2-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C2-X-1 (R16533282Z) is a high-precision ball runner block designed for linear motion applications requiring extreme accuracy and rigidity. This runner block is part of the Ball Rail Systems product line, which ensures smooth and precise movement in various industrial settings. The B.RUNNER BLOCK CS features an unalloyed steel CS body with a size FLS format, which includes a width flange, long length, and standard height. It offers extra precision (accuracy class XP) without the use of a ball chain. This model is preloaded to medium preload class C, ensuring a balance between rigidity and motion smoothness. The runner block comes with initial lubrication and preservation for long-term performance, utilizing Roller bearing grease Dynalub. It does not include attachment elements on either front reference edge but provides straight lube connection loosely attached. The product boasts several advanced features such as patented entry zone for enhanced travel accuracy, all-round sealing for protection against contaminants, high torque load capacity, and compatibility with different preload classes for varied application requirements. Additionally, it has been engineered to support applications with just one runner block per rail due to its high rigidity in all load directions. Designed to be interchangeable with guide rails of every accuracy level within the system, this runner block can be used on all SN/SNO ball guide rails while maintaining the same high load ratings in all four main directions of loading. Moreover, it supports optional integration of an inductive and wear-free measuring system for precise control over movements. With its robust construction and dynamic capabilities, the Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C2-X-1 (R16533282Z) is well-suited for demanding applications where precision linear movement is critical.
