BALL RUNNER BLOCK CARBON STEEL KWD-035-FLS-C3-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C3-X-1 (R16533382Y) is a high-precision ball runner block designed for linear motion applications that demand exacting tolerances and rigidity. This runner block is part of the B.RUNNER BLOCK series, with a size code of KWD-035, indicating specific dimensions and capacities. The FLS format signifies a flanged, long, standard height configuration, providing versatility for different mounting scenarios. Crafted from unalloyed steel CS, the runner block boasts a high preload class C for robust performance under load and an accuracy class XP for extra precision movements. The inclusion of a ball chain ensures smooth travel behavior and reduced noise levels during operation. The product also features initial lubrication and preservation with roller bearing grease Dynalub for extended service intervals. The design incorporates straight lube connections that are loosely attached and allows for attachments to be mounted from both above and below the block. Additionally, it comes without attachment elements on either front reference edge but includes two extra mounting screw holes at the center for improved rigidity under liftoff and side loading conditions. With an overall length of the runner block specified in the model code, this product is interchangeable with guide rails across every accuracy level. It's engineered to meet stringent requirements in terms of reduced frictional oscillations and low friction force levels, especially when subjected to external loads. The runner block is suitable for applications requiring maximum precision due to its patented entry zone that enhances travel accuracy significantly. Furthermore, this model offers long-term lubrication capabilities spanning several years and features all-around sealing to protect against contaminants. Its high torque load capacity along with different preload classes allow it to accommodate various application requirements. This ball runner block can be utilized on all SN/SNO ball guide rails by Bosch Rexroth, ensuring compatibility and ease of integration into existing systems while maintaining high load ratings in all four main loading directions.
