BALL RUNNER BLOCK CARBON STEEL KWC-055-SNS-C2-P-2

Manufacturer: Bosch Rexroth

Material #: R162252210

Model : B.RUNNER BLOCK CS KWC-055-SNS-C2-P-2


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SNS-C2-P-2 (R162252210) is a state-of-the-art ball runner block designed for high precision and heavy-duty applications. This runner block is part of the Ball Rail Systems product line, specifically crafted for use in environments where space constraints demand a slimline width yet require normal length and standard height. Fabricated from high-quality carbon steel (CS), this runner block guarantees robust performance with its medium preload class C and precision accuracy class P. The product is distinguished by its lack of a ball chain, ensuring a simplified design while maintaining high performance. It comes preserved but without initial lubrication, allowing users to apply the lubricant best suited for their specific application needs. The runner block features angular lube nipples loosely attached for ease of maintenance. With an overall length of . mm, this runner block offers interchangeability with guide rails across all accuracy classes, making it versatile for various setups. It boasts impressive load capacities in all four main directions, ensuring stability and reliability even under high torque loads. The low noise level and excellent travel behavior make it suitable for applications that demand quiet operation. The B.RUNNER BLOCK CS KWC-055-SNS-C2-P-2 facilitates long-term lubrication over several years, reducing maintenance frequency. Its design includes endface fastening threads for attachments and can accommodate high rigidity requirements with just one runner block per rail if necessary. Key specifications include a static load rating C0, dynamic load capacity C, static and dynamic torsional moment load capacities Mt and ML respectively. The product is designed to operate within an ambient temperature range of min ... max °C (admissible for short periods), ensuring reliability across different working environments. Overall, the Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SNS-C2-P-2 delivers precision movement control in linear guide systems, catering to demanding industrial applications that require durability, low friction coefficients, and long service life without compromising on performance.

$581.69 USD

More are expected on February 25, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as February 25, 2025 when ordered in
