BRAKING ELEMENT MBPS 3005 AS1A
Manufacturer: Bosch Rexroth
Material #: R161974031
Model : BRAKING ELEMENT MBPS 3005 AS1A
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BRAKING ELEMENT MBPS 3005 AS1A (R161974031) is a high-performance pneumatic braking unit designed for dynamic and static stabilization in axial directions. This unit is engineered to be compatible with all SNS ball guide rails, ensuring versatility across various profiled rail systems including sizes A, B, D, E, H, N, and S. It features an integrated all-round sealing and boasts a robust construction with a solid, rigid steel housing that is chemically nickel-plated for durability.
With the capability to handle up to 1 million clamping cycles and up to 10,000 emergency braking operations, the BRAKING ELEMENT MBPS 3005 AS1A is built for longevity and reliability. It operates efficiently with low air consumption and does not require maintenance over its lifetime of 1 million cycles. The unit's mechanical gate valve gear mechanism provides high positioning accuracy while ensuring safety as it clamps and brakes without pressurization using spring energy.
This braking element can exert holding forces up to 22,000 N at just 5.5 bar release pressure due to its design incorporating three pistons connected in series alongside strong springs. It operates within a permissible ambient temperature range of -30°C to +80°C and has a nominal size that accommodates various runner block dimensions.
The functional principle of the BRAKING ELEMENT MBPS 3005 AS1A involves clamping and braking with spring force; in the event of pressure drop, it achieves the desired effect through a dual-acting gate valve gear mechanism equipped with a spring assembly energy accumulator. Additionally, an integrated quick-exhaust valve ensures short reaction times for efficient operation.
Overall, this product offers high continuous output with minimal air consumption while providing safe and precise control over machinery movements within industrial settings.
$2,594.15 USD
More are expected on March 7, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 7, 2025 when ordered in
