CLAMPING ELEMENT KWH 6505 AS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT KWH 6505 AS1A (R161964211) is a high-performance hydraulic clamping unit designed for use with ball rail systems. This compact and robust clamping element can be utilized on all SNS ball guide rails, offering versatility across various sizes of profiled rail systems, including Size A, B, E, H, N, and S. It features a solid and rigid steel housing that is chemically nickel-plated to ensure durability and resistance against environmental factors. With its special pressure diaphragm technology, the KWH 6505 AS1A maintains maximum functional reliability without experiencing pressure losses or leakage. This technology also facilitates a consistently adjustable pressure range from 50 to 350 bar. The integrated positivelocking and large-surface contact profiles contribute to exceptional axial rigidity while also providing high positioning accuracy. The unit boasts a significant holding force capability and has been tested for up to 1 million clamping cycles to guarantee longevity. It operates on a hydraulic pressure principle where the clamping profiles are pressed onto the flanks of the ball guide rail via a piston mechanism under pressure (50-350 bar), while decompression is achieved swiftly through spring force. Designed with integrated all-around sealing, the KWH 6505 AS1A ensures protection against contaminants. It features threaded connections on both sides for hydraulic integration and supports a wide range of ambient temperatures from -10°C up to +80°C without compromising its functionality. Additionally, this model has been engineered for easy installation with minimal maintenance requirements, making it suitable for demanding applications that require reliable clamping under varying operational conditions.
