BALL NUT SEM-E-C 20X20RX3,5-3

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SEM-E-C 20X20RX35-3 (R151217055) is a high-precision ball screw assembly designed for linear motion applications requiring meticulous control and reliability. This adjustable preload single nut SEMEC is crafted to deliver exceptional performance with a nominal diameter of 20 mm and a lead of 20 mm, suitable for right-hand thread direction. It features a flange type C mounting, which aligns with DIN standards, ensuring compatibility and ease of integration into various mechanical setups. The SEM-E-C 20X20RX35-3 is equipped with standard seals and standard axial clearance, maintaining its operational integrity by protecting against contaminants. The ball screw assembly is designed to tolerate a dynamic load capacity (C) and static load rating (C0), both specified for tolerance grades T3 and T7. Users should note that these capacities are applicable only to these tolerance grades; other grades may require adjustments based on the correction factor fsubacsub. This product operates within a temperature range of -10°C to +80°C, sustaining continuous use at temperatures up to +80°C and accommodating temporary peaks up to +100°C without compromising performance. The maximum permissible linear speed (vmax) is denoted in the technical specifications, ensuring users can optimize the speed according to their application requirements. The SEM-E-C 20X20RX35-3 boasts an adjustable preload feature enabling zero-clearance operation, which is critical for applications demanding high precision and rigidity. Its design includes multiple circuits of ball tracks that enhance load-bearing capabilities while minimizing frictional resistance. With its robust construction and reliable performance, this Bosch Rexroth ball screw nut stands out as an essential component for sophisticated linear motion systems where accuracy and durability are paramount. The unit's weight and size dimensions are provided in the product overview, facilitating selection based on specific design criteria or space constraints within mechanical assemblies.
