SENSOR PACKAGE FLEX EFFECTOR SET SFE-00-02-400-500

$7,665.00 USD

Add to Cart

Status: This product is temporarily out of stock.

Qty: Delivered as early as June 27, 2024 when ordered in

SENSOR PACKAGE FLEX EFFECTOR SET SFE-00-02-400-500

Unpacked Weight: 1.400 kg

Operation ambient temperature	+5... +50 °C
Protection class SFE	IP54
Sampling rate footnote	at a baud rate of 921600 Bd
Productgroup ID	17
Sampling rate	10
Manipulator connection	ISO 9409-1 31,5-4-M5 / 40-4-M6 / 50-4-M6
Housing material	Aluminum, hard anodized
Manipulator connection footnote	Standard
Maximum handling weight	6
Spring rate path compensation in axial direction XY and 0-2mm	12
Spring rate path compensation in axial direction Z	12
Locking time	<0.4
Compensation path XY	±3
Locking time footnote	Vertically suspended load
Generation SFE	00 First generation
Type of robot flange SFE	400 ISO 9409-40-4-M6
Type of adapter plate SFE	500 adapter for ISO 9409-50-4-M6
Tolerance for supply voltage	-10... +20 %
Compensation angle Z	±6.8mm
Maintenance	lifelong lubrication
Compensation path Z	-3
Power supply voltage	24
Compensation angle XY	±3.4mm
Maximum load torque Mx My	15
Max. load torque Mx, My footnote	Locked state
Mass of system footnote	without adapter plate
Spring breakaway force	6
Mass of system	1.3
Maximum current footnote	during locking/unlocking
Rated current	1
Maximum current	1.5
Weight	1.400
