LINEAR-SET LSSDR1T-12-WV-400

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR1T-12-WV-400 (R109721280) is a high-quality linear motion system designed for precision applications requiring robustness against cocking loads and high dynamic load capacity. This linear set includes a precision steel shaft with a diameter of 12 mm and standard length, featuring one ball guide groove for smooth, precise movements. The system is equipped with two torque-resistant linear bushings that are pre-set to zero clearance ex works, ensuring optimal performance from the outset. The tandem ball guide grooves provide stability and the torquetransmitting, hardened steel bearing plates contribute to the reliability of the system under various loading conditions. Notably, this model is supplied without external seals, making it suitable for environments where seals are not necessary or could interfere with operation. With a dynamic load capacity (C) that ensures minimal values even when both linear bushings are under equal load, this linear set can handle challenging tasks. Its static load rating (C0) and dynamic torsional moment load capacity (Mt) further attest to its capability to withstand significant forces during operation. This LINEAR-SET is part of product group ID Tandem (T), indicating that it includes two linear bushings in tandem configuration for enhanced load distribution. The maximum permissible ambient temperature range for this model spans from -20°C to +80°C, allowing it to function effectively in various climatic conditions. Additionally, it can achieve a maximum permissible linear speed (vmax), which speaks to its efficiency in rapid motion applications. The outer diameter (D) of the shaft and mass per meter (m kg/m) are engineered to provide an optimal balance between size and weight without compromising performance. Overall, Bosch Rexroth's LINEAR-SET LSSDR1T-12-WV-400 offers a reliable solution for demanding linear motion requirements across numerous applications.
