LINEAR-SET LSGF-B-40-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-B-40-DD (R108184040) is a high-precision linear motion component designed for robust and accurate linear guidance. This linear set comprises a steel flange, a standard precision flanged housing made of lamellar graphite cast iron, and a super linear bushing B that lacks self-alignment features. It is equipped with two retaining rings and two additional spacer rings made of steel, suitable for shaft diameters up to 40mm. The integrated wiper seals on both sides ensure the protection of internal components from contaminants. The LINEAR-SET LSGF-B-40-DD is characterized by its non-adjustable radial clearance and absence of initial lubrication, which allows users to apply their preferred lubricant based on specific application requirements. The friction force generated by this model is noted as the frictional drag that occurs when the bushings are not under radial load, influenced by speed and lubrication conditions. With an outer diameter of size V and size E, this linear set can withstand a maximum ambient temperature range from -20°C to +80°C. It has been tested for maximum permissible speeds (vmax) up to 5 m/s; however, it's important to note that at these speeds, the service life may be reduced due to increased wear on plastic parts. Tests have indicated that total travel can range from 100 km² to 200 km² without failure. This unit has a static load rating C0 and dynamic load capacity C1 suitable for various applications requiring precise linear movement. The LINEAR-SET LSGF-B-40-DD weighs 3.7 kg and can handle breakaway forces efficiently while providing reliable performance in vertical shaft designs as part of the modular Linear Set series. Its robust construction ensures durability and maintenance-free operation in numerous industrial applications.
