TOLERANCE RING AN45X12

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN45X12 (R081004501) is a precision-engineered component designed to provide a fixed and secure connection between machine parts. This tolerance ring is crafted from carbon steel, ensuring high temperature stability and resistance to various chemical stresses. With its circumferential flat edges located on the outer diameter, the AN45X12 model is tailored for use with standard nominal shafts, facilitating quick and economical installations. The tolerance ring boasts a large tolerance zone, allowing it to compensate for differences in thermal expansion between connected elements made of dissimilar materials. This feature eliminates the need for keyways or other positive-locking connections, simplifying the design of connecting parts. The AN type tolerance ring's specifications include a diameter (size d) and width (size b), both critical dimensions that contribute to its transferable torque capacity and permissible radial load. Designed for durability and cost-effectiveness, the Bosch Rexroth AN45X12 tolerance ring is an extremely low-cost machine element that does not compromise on quality or performance. It ensures a reliable mechanical fit within a wide range of applications, accommodating special size requirements upon request. Users can expect a robust connection that withstands demanding operational conditions while streamlining the assembly process. The product's weight and specific transferable torque values are detailed in technical documentation, which should be consulted to ensure proper usage and installation according to Bosch Rexroth guidelines.
