LINEAR-SET LSAS-A-25-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAS-A-25-DD (R107162520) is a high-quality linear motion component designed to provide smooth and precise linear movement in various applications. This linear set is comprised of an aluminum housing with a side opening, which facilitates easy installation and maintenance. It includes a super linear bushing A with a self-alignment feature, ensuring reliable guidance and extended service life even under misaligned conditions. The LSAS-A-25-DD features a lightweight precision housing made from aluminum, offering an excellent strength-to-weight ratio for applications where weight is a critical factor. The set comes with two external seals that protect the internal components from contaminants, enhancing durability and performance reliability. The seals also contribute to the unit's ability to handle dynamic load capacities effectively while maintaining low frictional drags, thanks to its integrated wiper seals on both sides. With a shaft diameter of 25 mm, this linear set is designed for standard applications requiring high accuracy and repeatability. It can withstand maximum accelerations and operate within an ambient temperature range of -20°C to +80°C without compromising its functionality. The outer diameter of the bushing ensures compatibility with corresponding components within the system. The LINEAR-SET LSAS-A-25-DD boasts impressive load capacities in the main direction of loading, ensuring it can handle significant forces from all directions without reducing its load capacity. Its design also prevents loads exerted counter to the direction of opening from causing considerable reductions in load capacity—a common issue with open linear bushings. This model is capable of achieving maximum permissible speeds up to 5 m/s, although it's important to note that at these speeds, the service life may be limited due to increased wear on plastic parts. Nevertheless, tests have demonstrated that this linear set can achieve total travel ranging from 100 km² to 1000 km² without failure. Overall, the Bosch Rexroth LINEAR-SET LSAS-A-25-DD (R107162520) represents an efficient solution for designers seeking a robust and reliable linear motion system component that ensures precision movement while absorbing forces effectively in various industrial applications.
