LINEAR-SET LSATOE-A-25-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSATOE-A-25-DD (R103462520) is a high-precision linear motion set designed for various applications requiring guided linear movement. This set includes a lightweight precision tandem housing made of aluminum, which houses two super linear bushings A. These bushings come with integrated wiper seals on both sides to ensure protection against contaminants and provide longevity to the system. The LSATOE-A-25-DD features an adjustable open design that facilitates easy installation and maintenance, along with a self-alignment feature that enhances performance by allowing for minor misalignments. Equipped with external seals and the capability to be relubricated, this linear set offers increased durability and reduced maintenance requirements. It can accommodate a shaft diameter 'd' while delivering smooth motion thanks to its standard version construction. The set is also characterized by its reference edge, which aids in precise alignment during installation. The dynamic load capacity C indicates the load capacity when both linear bushings are under equal load, focusing on the main direction of loading. The static load rating C reflects the load capacity under static conditions. With maximum permissible linear speed vmax, this linear set can achieve speeds up to 'vmax' m/s, although service life may be limited by increased wear on plastic parts at higher velocities. Additionally, the LINEAR-SET LSATOE-A-25-DD has been tested for total travel ranging from 'lower limit' m to 'upper limit' m without failure, demonstrating its robustness and reliability in operation. It also features an adjusting screw for radial clearance adjustments, allowing it to be configured for zero clearance or preloaded guides as needed. This product comes clamped to h shaft lower limit and is set to zero-clearance out of the box. With a broad range of permissible ambient temperatures and dynamic as well as static longitudinal moment load capacities, Bosch Rexroth's LSATOE-A-25-DD offers versatility for various industrial applications requiring precise linear guidance.
