LINEAR-SET LSGE-A-30-DD
Manufacturer: Bosch Rexroth
Material #: R106663040
Model : LINEAR-SET LSGE-A-30-DD
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGE-A-30-DD (R106663040) is a comprehensive linear motion system designed for precision and durability. This linear set is crafted from steel and features an adjustable super linear bushing A with a self-alignment feature, ensuring smooth and accurate motion. The lamellar graphite cast iron housing provides robust support, while the integrated wiper seals on both sides maintain cleanliness by preventing the ingress of contaminants, which is essential for maintaining the system's integrity and prolonging its service life.
With a shaft diameter of 30 mm, this model comes equipped with two seals that contribute to its normal precision rating. The set is engineered to handle dynamic load capacities effectively, with specific load capacity values depending on the direction of loading. For instance, certain factors need to be applied if the loading direction deviates from the main direction.
The LINEAR-SET LSGE-A-30-DD can withstand maximum accelerations (amax) and operate within a permissible ambient temperature range, ensuring reliability across various working conditions. The outer diameter D and breakaway force are specified to meet application requirements, while the maximum permissible linear speed (vmax) highlights its capability for high-speed operations.
This product also boasts an impressive static load rating C and comes clamped to an h6 shaft lower limit with zero-clearance pre-set. It is suitable for applications requiring precise guidance with minimal frictional drag, which is quantified in the provided specifications.
The weight of the unit is carefully considered to balance durability with ease of handling, making it ideal for various industrial applications. Additionally, it features an adjusting screw for radial clearance adjustments to achieve zero-clearance or preloaded guides as needed by specific applications. With its comprehensive design and robust build quality, this Bosch Rexroth linear set ensures reliable performance in demanding linear motion tasks.
$147.51 USD
More are expected on March 14, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 14, 2025 when ordered in
