LINEAR-SET LSG-M-30-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSG-M-30-DD (R106523000) is a high-precision linear motion set designed for a variety of applications requiring smooth and accurate guidance. This product features a closed steel linear set with standard LB metal, specifically crafted for durability and performance. The precision housing is made from lamellar graphite cast ironsteel, ensuring a robust structure for the standard linear bushing which comes with wiper seals to provide protection against contaminants. Equipped with two retaining rings, the LINEAR-SET LSG-M-30-DD has a shaft diameter 'd' that is meticulously engineered to achieve optimal radial clearance values, contributing to the system's precision. The radial clearance is determined by considering both the working bore diameter and shaft tolerance statistics. Additionally, this linear set has been designed to accommodate dynamic loads with minimal values due to variable orientations and loading directions. The dynamic load capacity 'C', static load rating 'C', friction force, maximum acceleration 'amax', breakaway force, and maximum permissible linear speed 'vmax' are all specified to ensure reliable operation under different conditions. The product can operate within a permissible ambient temperature range, making it suitable for diverse environments. This Bosch Rexroth linear set is part of their standard metal series and weighs in at an efficient mass, balancing sturdiness with ease of handling. As part of their product group ID offerings, this model ensures compatibility with various industrial applications while maintaining Bosch Rexroth's quality standards in linear motion technology. The LINEAR-SET LSG-M-30-DD is an exemplary solution for users needing closed format linear bushings that deliver dependable performance in demanding scenarios.
