LINEAR-SET LSGE-B-30-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGE-B-30-DD (R106683040) is a high-precision linear motion set designed for various applications requiring smooth and accurate linear movement. This product features a robust construction with a precision housing made of lamellar graphite cast iron and steel. It includes a super linear bushing B, which is notable for its lack of self-alignment feature, ensuring stable and precise motion. The set integrates wiper seals on both sides to protect against contaminants, extending the life of the product. The LINEAR-SET LSGE-B-30-DD is adjustable, allowing for zero-clearance or preloaded configurations thanks to an adjusting screw that modifies radial clearance as needed. It comes clamped to the h6 shaft lower limit and is preset to zero-clearance for immediate installation without additional adjustments required by the user. Equipped with a shaft diameter 'd' and an outer diameter 'D', this linear set ensures compatibility with various design requirements. The dynamic load capacity 'C' indicates the product's ability to handle loads effectively in its main direction of loading but also provides factors for load capacities when loaded in non-primary directions. With a static load rating 'C' and capable of accommodating maximum accelerations 'amax', it maintains performance within a permissible ambient temperature range from minimum to maximum degrees Celsius. The breakaway force and maximum permissible linear speed 'vmax' highlight the component's capability to operate at high speeds—up to 5 m/s—although service life may be limited due to increased wear on plastic parts under such conditions. This linear set has been tested for total travel ranging from 10^4 m to 10^7 m without failure, proving its durability and reliability in demanding applications. Weighing at . kg, it presents an optimal balance between strength and weight, making it suitable for various industrial uses where precision linear guidance is essential.
