SHAFT SUPPORT RAIL WU60-AF-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU60-AF-600 (R105056000) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is particularly suited for applications requiring very low height configurations. It is made from aluminum with a flange version, providing a lightweight yet robust support system for linear motion setups. With a standard length as specified in the manufacturer's table, the WU60-AF-600 is engineered to work seamlessly with open linear bushings. It is ideal for long guides or heavy load conditions where self-supporting shafts are impractical due to potential shaft warping. The design allows for unlimited length configurations when used with interconnecting shafts, making it versatile for various application lengths. The careful adaptation of the support rail to match the linear bushing size results in an optimal pressure angle that ensures extra rigidity when fitting the shaft. This feature, combined with the use of large fastening bolts, contributes to the overall stability and performance of the assembled guide. Bosch Rexroth's SHAFT SUPPORT RAIL WU60-AF-600 offers additional degrees of freedom in the circumferential direction compared to profiled guide rails. This makes it an excellent choice for scenarios where other linear guides may experience warping due to imprecise substructures. Overall, this product represents a reliable solution within Bosch Rexroth's line of precision steel shafts with shaft support rails, designed to meet various requirements and enhance the functionality of linear motion systems.
