SHAFT SUPPORT RAIL WU40-AF-600
Manufacturer: Bosch Rexroth
Material #: R105054000
Model : SHAFT SUPPORT RAIL WU40-AF-600
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU40-AF-600 (R105054000) is a high-quality component designed for creating precise linear guides, particularly suitable for applications requiring low height configurations and extra rigidity. This shaft support rail is manufactured from aluminum with a flange version, ensuring a lightweight yet robust construction. It has been meticulously designed to achieve the ideal pressure angle when paired with an appropriate linear bushing, which helps in maintaining extra rigidity and stability during operation.
The WU40-AF-600 shaft support rail is compatible with open linear bushings and is an excellent choice for long guides or scenarios involving high loads where self-supporting shafts are not viable due to potential warping. It offers the flexibility of creating unlimited length guides by interconnecting multiple shafts. This feature makes it adaptable to various requirements and provides additional degrees of freedom in the circumferential direction compared to profiled guide rails.
Bosch Rexroth's attention to detail extends to the careful adaptation of the support rail to match the linear bushing size, which is critical for ensuring a proper fit and optimal performance of the shaft. This product stands out for its versatility and can be used in situations where other linear guides might fail due to imprecise substructures.
The specifications of this model include standard lengths as per available tables, aluminum material construction for both the rail and the flange, compatibility with precision steel shafts, and options for various sizes (V, A, H) and angles. The product group ID indicates its categorization within Bosch Rexroth's range of linear motion products. The weight and tolerance specifications ensure that users can select the right component based on their precise design requirements.
$112.88 USD
More are expected on March 31, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 31, 2025 when ordered in
