SHAFT SUPPORT RAIL WU30-AF1-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU30-AF1-600 (R105063000) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is particularly suitable for applications requiring extra rigidity due to its careful adaptation to the linear bushing size, ensuring an ideal pressure angle for fitting the shaft. The use of large fastening bolts further enhances this rigidity. It is made from aluminum and features a flange with a standard bore spacing type, providing additional degrees of freedom in the circumferential direction compared to profiled guide rails. This model is intended for use with open linear bushings and is ideal for long guides or high-load scenarios where self-supporting shafts are not feasible because of potential shaft warping. It allows for unlimited length configurations when using interconnecting shafts, making it versatile for various application requirements. The product's design ensures that it can maintain stability and precision even on substructures that may be imprecise or prone to warping. The WU30-AF1-600 model has a standard length as per the table provided by Bosch Rexroth, with numerous key specifications such as thread diameter Mx, size V, size t, size A, product group ID, thread x lead Mx, size H, angle size E, bore spacing type, length L in aluminum material for the shaft support rails. It also specifies the shaft diameter d and includes details on the weight and tolerances. Overall, this Bosch Rexroth shaft support rail is an essential component for engineers looking to construct reliable linear guides that can handle demanding conditions without compromising on precision or load-bearing capacity.
