SHAFT SUPPORT RAIL WU20-AF-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU20-AF-600 (R105052000) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail, made from aluminum with a flange version, is specifically engineered to work in conjunction with open linear bushings. It offers an ideal pressure angle for fitting the shaft, ensuring that the assembly maintains extra rigidity through the use of large fastening bolts. The WU20-AF-600 is suitable for applications requiring long guides or bearing high loads where self-supporting shafts are not viable due to potential shaft warping. It also provides additional degrees of freedom in the circumferential direction, making it more adaptable than profiled guide rails in certain scenarios. This flexibility is particularly beneficial in situations where other linear guides may fail due to imprecise substructures. Bosch Rexroth's design allows for unlimited length configurations when using interconnected shafts, which broadens the scope of potential applications. The product group ID, size V, size A, size H, angle specifications as well as the length L and material specifics all contribute to its versatility and performance. In summary, the Bosch Rexroth SHAFT SUPPORT RAIL WU20-AF-600 stands out for its ability to support various requirements in linear motion applications. Its combination with precision steel shafts and its compatibility with different sizes of linear bushings make it a robust solution for ensuring stability and precision in demanding mechanical setups.
