SHAFT SUPPORT RAIL WU20-AF2-600
Manufacturer: Bosch Rexroth
Material #: R105072000
Model : SHAFT SUPPORT RAIL WU20-AF2-600
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU20-AF2-600 (R105072000) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is particularly suited for applications requiring a low-height linear guide system. It is made of aluminum with a flange and bore spacing type, ensuring it provides the necessary support for open linear bushings. The careful design of the rail allows for an optimal pressure angle when fitting the shaft, which in combination with large fastening bolts, contributes to the system's extra rigidity.
The WU20-AF2-600 model is capable of supporting long guides or handling high loads where self-supporting shafts are not viable due to potential shaft warping. Its design also permits unlimited length configurations through interconnecting shafts, offering versatility in application length requirements. Additionally, this support rail offers more degrees of freedom in the circumferential direction compared to profiled guide rails, making it an excellent choice for scenarios where other linear guides might fail due to imprecise substructures.
This product falls under Bosch Rexroth's product group ID related to aluminum shaft support rails and is compatible with precision steel shafts for enhanced performance in linear bushing and shaft systems. The model includes various specifications such as size O thread diameter Mx, size V, size t, size A, size O thread x lead Mx, size H angle, size E bore spacing type, and length L. It is designed to meet stringent tolerance requirements and provide reliable support in a range of industrial applications.
$94.99 USD
More are expected on February 27, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 27, 2025 when ordered in
