SHAFT SUPPORT RAIL WU16-AF-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU16-AF-600 (R105051600) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is specifically crafted from aluminum with a flange version, providing a robust and lightweight solution for supporting linear motion applications. The rail is engineered to work seamlessly with open linear bushings, making it an ideal choice for long guides or heavy load scenarios where self-supporting shafts are not viable due to potential shaft warping. This product offers unlimited length possibilities through the use of interconnecting shafts, thus accommodating various application sizes and requirements. The careful design ensures an optimal pressure angle when fitting the shaft, which is critical for maintaining extra rigidity in conjunction with large fastening bolts. Unlike profiled guide rails, this model offers additional degrees of freedom in the circumferential direction, which is particularly beneficial for applications suffering from warping due to imprecise substructures. The Bosch Rexroth SHAFT SUPPORT RAIL WU16-AF-600 comes in standard lengths as per the provided table and features a size V, A, H, M, and angle specifications that cater to different design needs. It falls under the product group ID designated for linear bushing and shaft systems. The aluminum material of the support rails contributes to its lightweight nature while ensuring durability and strength. Precision steel shafts can be combined with these support rails to form a complete linear guide system that can withstand various tolerances indicated by the prefix/suffix configurations. This component exemplifies Bosch Rexroth's commitment to providing versatile and reliable solutions for sophisticated linear motion requirements.
