SHAFT SUPPORT RAIL WU16-AF1-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU16-AF1-600 (R105061600) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is crafted from aluminum, featuring a flange and bore spacing type that adheres to standard length specifications. The product is engineered to provide additional rigidity when combined with linear sets, making it ideal for applications requiring low-height linear guides. The careful design ensures an optimal pressure angle when fitting the shaft, which, in conjunction with large fastening bolts, contributes to the system's overall stiffness. It is specifically intended for use with open linear bushings and excels in situations where long guides or high loads are present that might lead to shaft warping if self-supporting shafts were used. Bosch Rexroth's SHAFT SUPPORT RAIL WU16-AF1-600 offers unlimited length possibilities through the use of interconnecting shafts and provides support rails tailored to various requirements. This flexibility includes additional degrees of freedom in the circumferential direction compared to profiled guide rails, making it a superior choice for scenarios where other linear guides could fail due to imprecise substructures. With its precise manufacturing, this product ensures compatibility and enhanced performance for precision steel shafts with shaft support rails. Its aluminum construction not only contributes to its sturdiness but also keeps the weight manageable without compromising on strength or precision. The product belongs to a group of components that are integral in constructing dependable and accurate linear motion systems across a range of applications.
