LINEAR-SET LSAO-B-20-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAO-B-20-DD (R103782020) is a high-precision linear motion component designed for applications requiring robust guidance and a high degree of rigidity. This linear set is composed of an aluminum housing with an open design and features a super linear bushing B, which lacks self-alignment capabilities. The product is characterized by its lightweight precision housing made from aluminum and secured by a grooved taper pin. It includes external seals for protection and is relubricatable to ensure long service life. The shaft diameter 'd' of the unit allows for precise motion control, while the two integrated wiper seals on each side maintain cleanliness within the system and contribute to the frictional force experienced during operation. This frictional force varies depending on speed and lubrication conditions. The LINEAR-SET LSAO-B-20-DD offers excellent dynamic load capacity, ensuring it can handle the main direction of loading effectively. This linear set is capable of withstanding maximum accelerations and operates within a permissible ambient temperature range, ensuring reliability across various operational environments. Its outer diameter 'D' is optimized for long guides that require additional shaft support. Additionally, it has been tested to sustain a significant amount of total travel without failure, highlighting its durability. Suitable for use in settings where high-speed linear motion is necessary, this product can achieve speeds up to a specified maximum while maintaining performance integrity over time. The static load rating further underscores its capacity to withstand loads without movement. In summary, the Bosch Rexroth LINEAR-SET LSAO-B-20-DD (R103782020) is engineered for applications that demand precise linear guidance with high rigidity and durability. Its construction quality and capability to maintain performance under various conditions make it an essential component in sophisticated linear motion systems.
