TORQUE RESISTANT BUSHING KBDR1-40-WV-900

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-40-WV-900 (R069604085) is a high-precision component designed for self-supporting, torsionally stiff linear guides that require only one shaft. This torque-resistant linear bushing is crafted without a seal and comes standard with a precision steel shaft that includes a single ball guide groove, which is essential for transferring torques effectively. The bushing's outer sleeve and ball retainer are constructed from durable materials such as PA or POM, ensuring longevity and consistent performance. With its hardened steel bearing plates and balls made from rolling bearing steel, the KBDR1-40-WV-900 exhibits excellent durability under dynamic conditions. The product also features a hardened steel adjusting screw and a robust steel lock nut to maintain zero clearance settings, providing precise control over motion with minimal backlash. This model is particularly suited for applications where the direction of loading may not be clearly defined; hence, it comes with minimal values for dynamic load capacity (C) and static load capacity (C0), ensuring reliable operation within its specified limits. It can withstand a dynamic torsional moment load capacity (Mt), and operates efficiently within an ambient temperature range of -20°C to +80°C. The bushing's outer diameter measures D, while the maximum permissible linear speed (vmax) and acceleration (amax) ensure smooth motion profiles in various applications. With a mass of m kg/m, this product offers an excellent balance between weight and structural integrity. The Bosch Rexroth KBDR1-40-WV-900 is ideally formatted as a closed linear bushing and shaft system, making it an integral component for sophisticated mechanical setups requiring precise torque resistance capabilities.
