LINEAR-SET LSAE-A-40-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAE-A-40-DD (R103664020) is a high-quality linear motion system designed for precision applications. This linear set comprises an aluminum lightweight precision housing with a super linear bushing A, featuring a self-alignment capability that enhances its performance and reliability. The bushing is adjustable and relubricatable, ensuring longevity and ease of maintenance. Equipped with external seals, the LINEAR-SET LSAE-A-40-DD ensures protection against contaminants, contributing to the durability of the system. The shaft diameter is designated as 'd', and the set includes two integrated wiper seals on both sides, which are responsible for generating frictional drags when not under radial load. These drags depend on speed and lubrication conditions. The product boasts a standard version design tailored for various applications requiring precise linear motion. It has a dynamic load capacity (C) that must be adjusted based on the direction of loading, with specific factors provided for different shaft diameters. The maximum acceleration (amax), permissible ambient temperature range (-20°C to +80°C), outer diameter (D), breakaway force, maximum permissible linear speed (vmax), and static load rating (C) are all specified to ensure optimal functionality under designated operational parameters. The Bosch Rexroth LINEAR-SET is also characterized by its ability to handle speeds up to 5 m/s, although this is contingent upon increased wear to plastic parts within the assembly. Service life tests have indicated total travel ranging from 100 km to 10^5 km without failure. Furthermore, this product comes clamped to the h shaft lower limit and is preset to zero-clearance for immediate use in precision applications. With an emphasis on adjustability and performance, this linear set weighs approximately 1 kg and provides users with an efficient solution for their linear motion needs without requiring extensive setup or adjustment post-installation.
