LINEAR-SET LSGF-A-40-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-A-40-DD (R108164040) is a high-precision linear motion component designed to facilitate smooth and accurate linear movement in various applications. This linear set is composed of a flanged housing made from lamellar graphite cast iron, which includes a super linear bushing A with a self-alignment feature, ensuring reliable operation and ease of installation. The unit is equipped with two integrated wiper seals that help maintain cleanliness within the system by preventing the ingress of contaminants. The shaft diameter for this model is tailored to provide a secure fit, while two retaining rings and additional spacer rings made of steel ensure robustness and durability. The standard precision design of this product ensures consistent performance across a range of uses. Notably, the LINEAR-SET LSGF-A-40-DD does not require initial lubrication, simplifying maintenance procedures. This model boasts an impressive dynamic load capacity C, calculated based on a total travel distance of 100 km; for applications involving up to 50 km, the capacity values should be adjusted accordingly by multiplying by 1.26. It can handle maximum accelerations (amax) efficiently while operating within an ambient temperature range of -20°C to +80°C. The outer diameter D and size V specifications contribute to its adaptability in different settings. With its breakaway force and maximum permissible linear speed vmax, the LINEAR-SET LSGF-A-40-DD can achieve speeds up to 5 m/s; however, it's important to note that at these speeds service life may be affected due to increased wear on plastic components. Weighing approximately 2.7 kg and categorized under Productgroup ID for easy reference, this linear set is an integral part of vertical shaft design solutions within the Linear Set series by Bosch Rexroth. It offers both functionality and reliability for users seeking top-tier linear motion components.
