TORQUE RESISTANT BUSHING KBDRC2-20-WV-500

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDRC2-20-WV-500 (R072032080) is a high-quality, torqueresistant compact linear bushing designed for self-supporting, torsionally stiff guides with a single shaft. This product features precision steel shafts with machined ball guide grooves that are suitable for shaft diameters of 20 mm and above, with dual ball guide grooves from larger diameters. It is crafted without a seal and comes with the shaft included, ensuring standard length as per the provided specifications. The KBDRC2-20-WV-500 linear bushing incorporates hardened steel bearing plates and balls made from rolling bearing steel to ensure durability and smooth motion. The adjusting screw is also made of hardened steel and allows for zero-clearance setting, while the steel lock nut secures the components in place. The ball retainer and outer sleeve are constructed from robust materials such as PA or POM for additional resilience. This model is part of the Torqueresistant compact series within Productgroup ID Size N . It has been engineered to handle dynamic load capacities with minimal values due to variable loading directions. The ambient temperature range for operation spans from -30°C to +80°C, making it versatile for different working environments. Its outer diameter D is tailored to fit specific applications, and it can achieve maximum permissible linear speeds without compromising performance. With a weight of 0.5 kg/m, this bushing system minimizes additional mass on machinery while maintaining a static load rating C0 and dynamic torsional moment load capacity Mt that underscore its robustness in various applications. As a closed format linear bushing, it provides an integrated solution for precise linear motion requirements across numerous applications without requiring complex assembly or maintenance.
