LINEAR-SET LSAE-B-12-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAE-B-12-DD (R103681220) is a high-quality linear motion system designed for precision applications where smooth and accurate linear movement is required. This linear set comprises a lightweight precision aluminum housing and a super linear bushing B, which is adjustable and does not feature self-alignment, ensuring stable and precise motion. The shaft diameter d allows for compatibility with various design requirements, while the external seals provide protection against contaminants, extending the lifespan of the unit. Equipped with two integrated wiper seals on each side, the LINEAR-SET LSAE-B-12-DD reduces frictional drags which depend on speed and lubrication conditions. The set is relubricatable, allowing for maintenance that can prolong service life. Notably, this model has a maximum acceleration (amax), a specific range of permissible ambient temperatures from -20°C to 80°C, and an outer diameter D tailored to size H specifications. The unit comes with detailed load capacity information to ensure optimal performance under various loading directions. For instance, its dynamic load capacity C and static load rating C are stipulated for sizes E, H, M, N, L, and S. The breakaway force for size H and maximum permissible linear speed (vmax) are also provided to guide users in their applications. The LINEAR-SET is pre-adjusted to zero clearance or can be preloaded using an adjusting screw to modify radial clearance as per application requirements. It boasts an impressive service life with potential total travel ranging from 100 km to 1000 km without failure under specified conditions. Furthermore, its weight of 0.45 kg makes it suitable for applications where system mass is a critical factor. Overall, the Bosch Rexroth LINEAR-SET LSAE-B-12-DD stands out as a robust solution for precise linear guidance in various industrial applications where reliability and accuracy are paramount.
